SPECIFICATIONS
| Normal continuous power | 4500 watts |
| Max power | 5500 watts |
| RMS power | 2500 watts |
| Nominal chassis diameter | 15” inches |
|
Voice coil diameter |
101.6mm (4 inches) |
|
Voice coil material |
Inside-outside (CCAW) |
|
Frequency range |
|
|
Sensitivity |
84 dB |
|
Nominal impedance |
Dual 4Ω |
|
Magnet material |
Ferrita |
|
Net weight |
20.5 Kg |
|
Revc |
3.6Ω |
|
Fo |
44Hz |
|
Sd |
83mm |
|
BL |
14 |
|
Qms |
5.9 |
|
Qes |
1.97 |
|
Qts |
1.48 |
|
Erm |
0.65 |
|
Vas |
33.17mm |
MOUNTING/SHIPPING INFORMATION
|
Overall diameter |
15/381 |
In/mm |
|
Bolt circle diameter |
14.7/373 |
In/mm |
|
Baffle cutout diameter |
14.3/363 |
In/mm |
|
Depth |
8.5/216 |
In/mm |
|
Net Weight |
20.5 |
Kg |
|
Shipping Weight |
22.9 |
Kg |
|
Shipping Box |
46.5x45x31 |
cm |
