ESPECIFICACIONES
| Max power | 1000 watts |
| RMS power | 500 watts |
| Nominal chassis diameter | 10” inches |
|
Voice coil diameter |
75.5mm (3” in) |
|
Voice coil material |
Inside-outside (GPICCAW) |
|
Frequency range |
65-4500Hz |
|
Sensitivity |
98 dB |
|
Nominal impedance |
8Ω |
|
Magnet material |
Ferrite | 77 OZ |
|
Net weight |
6.85 KGS |
INFORMACIÓN DE MONTAJE Y ENVIO
|
Overall diameter |
10” / 254 |
In/mm |
|
Bolt circle diameter |
9.8” / 249 |
In/mm |
|
Baffle cutout diameter |
9.5” / 241 |
In/mm |
|
Mounting Depth |
4.3” / 109 |
In/mm |
|
Net Weight |
7.2 |
Kg |
|
Shipping Weight |
7.8 |
Kg |
|
Shipping Box |
29*29*15 |
cm |
